MaxLink PoE Convertorr, 802.3af/at to 24V 24W

POE-CON-AFAT-24
Maxlink POE-CON-AFAT-24 is an indoor PoE converter that changes active power supply to passive. It converts from input PoE 802.3at (44-56V) to passive 24V.Input: 802.3at (44-56V)Output: 24V, max. 1AEthernet speed: 10/100/1000MbpsCable length: approximately 24 cm (from the output to the tip of the c... More information

Product description

Maxlink POE-CON-AFAT-24 is an indoor PoE converter that changes active power supply to passive. It converts from input PoE 802.3at (44-56V) to passive 24V.

  • Input: 802.3at (44-56V)
  • Output: 24V, max. 1A
  • Ethernet speed: 10/100/1000Mbps
  • Cable length: approximately 24 cm (from the output to the tip of the connector)

Specifications

Connectors and Interfaces

Ethernet speed [Mb/s]:10/100/1000
Gigabit LAN:Yes

Power

Pin powering:4,5 (+), 7,8 (-)
Output Power / 1port [W]:24
PoE-Out standards:Passive 24V
PoE Out ports:1
Output Voltage [V]:24

Physical characteristics

Operating temperature [°C]:0 up to 40
Weight [g]:55
Height [mm]:23
Width [mm]:30
Depth [mm]:80

Download
